Engineering Piping PTFE Rods, High Performance Plastic PTFE, Modified PTFE

Engineering Piping PTFE Rods, High Performance Plastic PTFE, Modified PTFE

PTFE material resists attack by heat and virtually all chemicals. It is insoluble in all organics with the exception of
Basic Info
Model NO. PTFE
Modulu of Elasticity(Gpa) 0.35-0.5
Elongation at Break(%) 150-350
Shore D 50-65
Temperature Range -196-260 Celsius
Coefficient of Linear Themal Expansion 1.0
Transport Package Export Carton, Pallet
Specification full specification
Trademark hdgfz
Origin China
HS Code 3902100090
Production Capacity Big&Stable
Product Description
PTFE material resists attack by heat and virtually all chemicals. It is insoluble in all organics with the exception of a few exotic strong base chemicals. Its electrical properties are excellent. Although it has high impact strength, its resistance to wear, tensile strength and creep resistance are low in comparison to other engineering type thermoplastics. Mechanical properties can be improved by adding fillers such as glass fibers, bronze, Delrin, carbon, and graphite.PTFE rod, sheet and tube exhibits the lowest electric constant and lowest dissipation factors of all solid materials. Because of its strong chemical linkage, PTFE tube, rod and sheet shows very little attraction for dissimilar molecules. This results in a coefficient of friction as low as 0.05. Once again, because of this chemical bonding, PTFE plastic resins are virtually insoluble

Main Properties:
Inertness to most chemicalsResistance to high temperaturesZero moisture absorptionLow coefficient of frictionExcellent dielectric propertiesChemically resistantExcellent radiation resistanceRelatively insensitive to power frequencyTechnical Specification:
PropertyNormValue
DensityISO11832.14-2.2
Tensile strength at break(Mpa)ISO52718-30
Modulus of elasticity(Gpa)ISO5270.35-0.5
Elongation at break(%)ISO527150-350
Shore DDurometer50-65
Temperature range/-196-260 centidegree
Coefficient of linear thermal expansion ISO113591.0

Main Products Available:
1). PTFE Sheet (Skived sheet and mold compression board)2). PTFE Rod ( Extruded rod and mold compression rod )3). PTFE Pipe/Hose (full specification)4). PTFE Extruded Tube(full specification)5). PTFE etched sheet, PTFE with filler(carbon, glassfiber, bronze, graphite...Etc. )6). PTFE machined partsNote: Special sizes can be customized for customers specified requirements.
